1000l three vessel complete craft beer brewery brewing equipment

  • >=1 Sets
    $22,999.00
Model Number:
NDL-1000L
Shipping:
Support Sea freight
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 50 Negotiable
Customization:
Customized packaging (Min. Order: 1 Sets)
Graphic customization (Min. Order: 1 Sets)

More

Customized logo (Min. Order: 1 Sets) Less
Samples:
$150.00 /Set | 1 Set (Min. Order) | Buy Samples
Report Suspicious Activity
Overview
Quick Details
Processing:
Fermenting Equipment
Applicable Industries:
Hotels, Manufacturing Plant, Food & Beverage Factory, Restaurant, Food Shop, Food & Beverage Shops
After Warranty Service:
Video technical support, Online support
Local Service Location:
Canada, United Kingdom, United States, Germany, Australia
Showroom Location:
Canada, United Kingdom, United States, Germany, Australia
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
NDL Craft
Processing Types:
Craft Beer
Voltage:
220/380V or customization
Power(W):
70KW
Dimension(L*W*H):
60 Cubic Meter
Weight:
5000KG
Certification:
CE ISO BV SGS
Warranty:
3 years
After-sales Service Provided:
Field installation, commissioning and training, Engineers available to service machinery overseas
Name:
1000l three vessel complete craft beer brewery brewing equipment
Material:
SUS304/SUS316/red Copper
Brewhouse type:
2/3/4 vessels
Heating way:
Electricity/Steam/Fire
Control system:
PID/PLC
Cooling way:
Dimple plate cooling
Cooling media:
Glycol water
Plate type:
Mirror polishing/2B/wire Drawing
Insulation:
Polyurethane/rockwool
Product Certification certification
CE Certified.
Valid from 2019-01-07 until 2024-01-06
Supply Ability
Supply Ability:
20 Set/Sets per Month 1000l three vessel complete craft beer brewery brewing equipment
Packaging & Delivery
Packaging Details
Plastic paper firstly then outside with iron frame ( standard wooden case) for LCL
Plastic film wrapped and steel frame fixing for FCL
Port
Qingdao/Tianjin/Shanghai/Ningbo/Shenzhen port and so on
Picture Example:
package-img
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 50 To be negotiated
Video Description

1000l three vessel complete craft beer brewery brewing equipment



Product Description
1. 1000L Brewery Configuration

Milling system

Malt miller

300-500kg/h

1pcs

Auger(option)

Ability is 1000KG/h

1pcs

Hopper(option)

Volume is 0.6m3. SUS 304 with pre-masher

1pcs

Brewhouse

Mash tun/ Lauter tank

Volume is 1000L, with false bottom, grant, raker with motor

1pcs

Kettle

Volume is 1000L, steam heating

1pcs

Whirlpool tank

Volume is 1000L

1pcs

HLT water tank

Volume is 2000L, steam heating

1pcs

Includes plate heat exchanger, wort pump, motors, hops filter, yeast adding tank, oxygen device and pipelines

Fermenting

Fermenters

Volume is 1000L or 2000L (double batches)

6pcs

BBT(option)

Volume is 1000L or 2000L (double batches)

2pcs

Racking arm, spunding valve, pressure gauge, carbonation stone, sample valve

Cooling system

Glycol tank

Volume 2000L or 3000L

1pcs

Cold water tank(option)

Volume 2000L, cooled by glycol tank

1pcs

Chiller

5HP, Copeland

2pcs

Cleaning

CIP

100L two tanks, heated by electric, with pump and trolley

1pcs

Controlling

Control cabinet

PLC touch screen or PID controller

1pcs



2. 1000L Mashing System With Three Vessels Brewhouse

NDL Craft experienced team of engineers and brewers work together to design every brewhouse. We meticulously focus on the details, like pump and valve placement, aiming to maximize brewhouse efficiency and ease of use. With a NDL CRAFT Brewhouse you will hit your gravity targets quicker and run up and down the platform less often.



A three-vessel brewhouse is hybrid system that incorporates at least one combination vessel and two dedicated process vessels. For example, a medium sized brewery with a focus on heavily hopped beers might choose to go with a combination Mash Lauter Tun, a dedicated Kettle, and a dedicated Whirlpool. Whereas, someone focusing on lagers or feeding a distilling operation might go with a dedicated Mash Tun, dedicated Lauter Tun, and a combination Kettle/Whirlpool. Three-vessel systems don’t have the same output and versatility as four-vessel systems, but they will still out perform a two-vessel system and provide increased efficiency.





Well-designed 3-vessel equipment, production efficiency increased by 30%
The new introduced production line has cut our operating costs by 30%



You May Also Like Other Brewhouse Types:



Send Inquiry>>

Click Here Contact Us Now!!!

3. 1000L Fermentation System

No.

Item

Introduction

01

Volume

1000L

02

Dimension

1260*2650mm

03

Material

Stainless steel 304 or 316,or red copper

04

Insulation

Polyurethane, TH: 80mm

05

Fermentation tank

Glycol jacket: Dimple jacket on the cone and side

Or single wall with jacketed,or single layer fermentor.

06

Head

Double or single dish head on the top

07

Accessories

Sample valve, pressure gauge, solenoid valve, pressure relief valve, racking arm, CIP arm and Blow off arm, dry hops port and so on.

Send Inquiry>>

Click Here Contact Us Now!!!



4. Brewery Auxiliary Equipment


5. Accessories
